JD450D STEERING CLUTCHES

The John Deere Model 450D's have oil type steering clutches and use 8 Friction discs p/n T82355 composite paper faced discs on a steel toothed base along with 8 steel separator plates p/n T31732. When later JD models were developed they used bimetallic discs to replace the earlier style fiber discs. Some owners prefer the earlier bimetallic friction discs. The bimetallic disc part number is T44129.  This was replaced by the paper faced friction discs T82355.  Some owners still prefer the Bimetallic discs so it is your choice.   The same numbers of discs were used in all circumstances. Most of the time you can get by with only changing the friction discs. The steel separator plates can usually be re-used. Check them for roughness, warping, or dishing and if they are clean, smooth, and straight, by all means re-use them!



                                uspsfreeshippingicon.jpg (27000 bytes)  In US only, via Priority Mail, 2-3 day delivery, on orders $500 or higher.

ORDERING INFO:
GRIMY_Man_SM.jpg (55040 bytes)  We can usually ship on the same day any items we have in stock that do not have to be pulled from a machine.
We are set up to offer the payment choices of either Visa, Master Card, or the PayPal option (to the account of webmaster@tractorparts.com)

All items below are in stock and if you would like to get any of them on the way just let us know!  If you are in the US you may call  1-800-531-9021 or if you are outside the US, 1 208 342 8911.  You may also email webmaster@tractorparts.com for orders/questions.

Our hours are Monday through Friday from 10 am Eastern Time to 6 pm Eastern Time (8 am Mtn Time to 4 pm Mtn Time).  We are located 20 miles east of Boise, Idaho.

FOR A WIDER SELECTION OF ALL OF OUR DISCS MADE
FOR MANY OF THE JOHN DEERE MACHINES....
CLICK HERE


T82355 Paper faced friction discs (8) required @ 25.00 ea
T44129 bimetallic disc, new aftermarket, NOW $22.00 ea
T31732 steel separator plates,(8) required,
$12.00 EA.

IF YOU DECIDE YOU NEED COMPLETE CLUTCH PACK...8 PAPERFACED FRICTION AND 8 STEEL..YOUR TOAL COST IS  $266 PER SIDE

IF YOU DECIDE YOU NEED COMPLETE CLUTCH PACK...8 BIMETALLIC FRICTION AND 8 STEEL..YOUR TOAL COST IS  $250 PER SIDE


JD450 450B BIMETALLIC & STEEL DISCS  T44129 BIMETALLIC FRICTION DISCS 22.00 EA  Will work for dry type or oil type cteering clutches


JD_450C_450D_450E_T82355_STEERING_CLUTCH_DISC_PAPER.JPG (340287 bytes)  T82355 FRICTION DISCS, PAPER FACED.  Some users prefer the paper over the bimetallic and some prefer bimetallic over paper faced discs. We provide both options. $25.00 EA




T31732_JD450B_CLUTCH_PLATE.JPG (93829 bytes) The T20717 steel separator plates(used in the earlier JD450's) are often confused with the T31732 plates used in the later steering clutches of the JD450C's.  To me sure which plates you have in your clutch the thickness should be measured.  The T20717 will measure closer to .087 while the later T31732 discs will be closer to .097-.099.  If the quantity of your discs varies from what is normally required, it is usually cause by the mis-use of the wrong steel separator plates. The depth of the brake drum was deeper in the 450C than the early 450 crawlers.


JD_T23861_BRAKE_BAND_RET_SPRING.JPG (182383 bytes)  BRAKE BAND RETAINER SPRINGS  T23861  NEW    $16.00 EA OR SET OF (2) @ 25.00
Also fits 450A,B,C's  550A,B,C's  RELATED TRACK LOADERS 455'S , 555'S and more.


JD9326_PILOT_BEARING_JD450_JD450B.JPG (141853 bytes)  JD9326 STEERING CLUTCH PILOT BEARING   $4.00  (ONE USED PER CLUTCH)



BRAKE BAND...   ONE PIECE BAND DESIGNED FOR OIL TYPE STEERING CLUTCHES ......We are currently in the process of making these and they should be ready after the first of the year @ $145.00 ea





Click HERE to view all of our new steering clutch discs.



CLICK HERE FOR DETAILS



Email  webmaster@tractorparts.com    For orders or questions.


CONTACT OUR OFFICE at 1-208-342-8911

General Gear and Machine, 733 Desert Wind Rd.,
Boise, Idaho, 83716  US
*All prices are in USD & do not include shipping
All prices are for new aftermarket unless stated otherwise
All OEM part numbers are for references only
